The Electronic torque adapters

TORQUE RANGE FROM 1.5 TO 340 NM

FACOM offer an electronic range, for high productivity and accuracy. Our wrenches and drives allow for increments in confined spaces.


adaptateur-E506-legendeSERIE E.506
  • 9 torque and/or angle values can be pre-set.
  • 50-result memory.

1- Electronic display LED & Buzzer.
2- 2 AAA-LR03 - 1,5V. batteries.
3- Gyroscope for angular reading.
4- Locking keypad.



adaptateur-E406SERIE E.406
  • 9 preset angle values.
  • 50-result memory

1- Electronic display LED & Buzzer.
2- 2 AAA-LR03 - 1,5V. batteries.
3- Magnetised tool (ratchet) fastening.
4- Gyroscope for angular reading.

ZOOM +
Electronic adapter Electronic adapter

WHY USE TORQUE/ANGLE TIGHTENING ?

Angle tightening eliminates friction issues related with torque tightening. The movement, and hence fastener tension, is defined by the screw pitch and tightening angle.

Torque/Angle tightening is performed
in 2 steps :
-Pre-torque for fitting parts and eliminating interface faults.
-Then screwing at a specific angle.

Proper tension in the assembly prevents unscrewing or breaking the screw.

E.506 SERIES

For occasional torque & angle tightening

apercu-1

E.406 SERIES

For basic angular tightening.

apercu-2
