High capacity 30 t outside puller
U.330
High capacity 30 t outside puller
- Versatile: takes 2 or 3 legs.
- Comfort: self-gripping legs by return spring. The puller stays in rolling position even when not in tension.
- Safety: legs locked in position on the bearing using a knob. No risk for the puller to escape from the bearing.
Additional Features
- The screw is supplied with an extension: U.330-14.
- Adaptable puller accessory: hydraulic jack UWG.330. Using the jack requires the screw UWG.330-H01 and hydraulic pump UWP.10M. Mounting with 3 legs only with the hydraulic jack.
- Capacity diameter 100-530 mm
- Capacity 30 t
Specifications
|
CE Mark
|
Yes
|
|
Hex Size [Metric]
|
41 mm
|
|
Number Of Legs
|
3
|
|
Special Grip
|
Yes
|
|
Number of Pieces
|
1
|
|
Max. Clip Capacity [Metric]
|
100-530 mm
|
|
Outside/ Inside Puller
|
Outside
|
|
Product Width [Metric]
|
900 mm
|
|
Puller Profile
|
Wide
|
|
Self Gripping
|
Yes
|
|
Stud Driver Diameter Type
|
Single Diameter
|
|
Product Height [Metric]
|
950 mm
|
|
Product Weight [Metric]
|
32.4 Kg
|
|
Width Capacity [Metric]
|
250 mm
|
|
Metric Ton (T)
|
30T
|
|
Number Of Spare Pins / Tips
|
1
|
|
Reversible
|
No
|
|
Type Of Puller
|
Special Grip Bearing Pullers
|
